Description

Conventional Recessed Heat Detector

The Conventional Fire Alarm Heat Detector is engineered to provide early, reliable thermal detection in environments where standard smoke detectors are prone to false alarms, such as kitchens, boiler rooms, and dusty industrial areas. Utilizing a highly stable thermal sensing element, this detector continuously monitors ambient room temperature to identify rapid thermal spikes or fixed high-heat thresholds.

With an adaptable non-polarized wiring design and automatic system reset, it seamlessly integrates into standard 2-wire, 3-wire, or 4-wire conventional fire alarm networks.

Key Features & Performance Advantages

  • High-Efficiency Coverage: Adequately monitors a detecting surface area of up to when installed at a standard ceiling height of 4 meters.

  • Ultra-Low Standby Consumption: Features an incredibly efficient micro-current draw of during normal monitoring conditions ($12\text{-}35\text{V}$).

  • Flexible Wiring Infrastructure: Features non-polarized connection architecture supporting universal 2-wire, 3-wire, or 4-wire configuration schemes for hassle-free field retrofits.

  • Intelligent Auto-Reset Function: Incorporates an automatic alarm reset capability (with an optional 0.5-second power-off reset) to reduce system downtime after testing or activation.

  • Wide Voltage Tolerance: Operates smoothly across a broad DC $10\text{V}$ to $35\text{V}$ power spectrum to protect against voltage fluctuations on the zone loop.

Technical Specifications

Parameter Specification
System Type

Conventional Fire Alarm Loop
Input Operating Voltage

DC 10V – 35V
Static / Standby Current

$\le50\mu\text{A} \ (12\text{V}-35\text{V})$
Alarm Status Current

$40\text{mA} – 80\text{mA} \ (12\text{V}-30\text{V})$
Detecting Coverage Area

Up to $60\text{m}^2$ (At 4-Meter Mounting Height)
Alarm Reset Mode

Auto Reset / Power-Off Reset ($0.5\text{s}$ optional)
Maximum Electrify Capacitance

0.03$\mu\text{F}$
Electrify / Power-Up Time

$\le60\text{ seconds}$
Operating Temperature Range

$-10^\circ\text{C}$ to $+55^\circ\text{C}$
Operating Humidity Range

10% to 95% RH (Non-coagulating)
Physical Dimensions

$\Phi105\text{mm} \times 46\text{mm}$ (Compact Profile)

Ideal Applications

  • Commercial Commercial Kitchens & Pantries

  • Multi-Device Hotel Corridors & Mechanical Rooms

  • Warehouses, Garages, and Loading Docks

  • Manufacturing Facilities and Dust-Prone Areas
